Product Introduction
Quartz flexible accelerometer is a precision instrument comprises quartz glass flexible support and advanced servo circuit based on the principal of inertia. When the carrier is subjected to acceleration, the output of the accelerometer is precisely proportional to the input acceleration. Our accelerometer has a current output form of high output impedance, and users can choose the sampling resistance according to their requirement without affecting the stability of the system.
At present, our quartz flexible accelerometer has formed a series of products, types from the high-precision μg GSACC111Q accelerometer for satellite microgravity measurement to low-cost, anti-harsh environment GSACC117Q accelerometer, as many as dozens, and widely used in aerospace, aviation, navigation, ship, vehicle, petroleum, geotechnical engineering and other fields, providing signals for navigation, guidance, control, leveling, monitoring and other systems.
Key Features
● Excellent index repeatability
● Analog output
● Small size and light weight
● Wide load resistance range
● Square precision mounting flanges
● Application in measurement system of oil drilling
● Two models are available
● It has good high temperature resistance
Application
● Inertial monitoring system
● Inertial navigation system
● Flight control system
● Vibration monitoring
● Oil drilling platforms and geological exploration
● Inertial measurement unit
● Motion monitoring equipment
Technical Specifications
| Parameter | GSQAMini125 | GSQAMini185 |
| Power supply parameter |
| Power Voltage | 12~18VDC | 12~18VDC |
| Power 25°C | 90mW | 90mW |
| Supply current | 6mA | 6mA |
| Product performance |
| Size | Ø18.8×21 | Ø18.8×21 |
| Bias | <20 mg | <30 mg |
| Bias stability | ≤100ug | ≤200ug |
| Bias temperature sensitivity | 100ug/°C | 100ug/°C |
| Bias repeatability | ≤100ug | ≤200ug |
| Scale factor | 2.2~3.5mA/g | 1.5~3.5mA/g |
| Scale factor temperature sensitivity | 200ppm/°C | 300ppm/°C |
| Second order nonlinear coefficient | ≤80μg/g² | ≤100μg/g² |
| Second order nonlinearity coefficient repeatability | ≤60μg/g² | ≤60μg/g² |
| Scale factor repeatability | 100ppm | 200ppm |
| Threshold | <10μg | <10μg |
| Resolution | <10 μg | <10μg |
| Bandwidth | <200 Hz | <200 Hz |
| Weight | ≤25g | ≤25g |
| Range | ±20 g | ±20 g |
| Environment |
| Operating temperature | -45°C～+125°C | -45°C～+185°C |
| Storage temperature | -55°C～130°C | -55°C～190°C |
| Random vibration | 20 grms | 20 grms |
| Shock | 1000g | 1000g |
Dimensions
